1 CHANNEL 4K30 HDMI2.0 USB3.0 EXTERNAL CAPTURE CARD - PD570 PRO HDMI2.0 HDR

If you need further assistance, have questions or would like an offer for this product, please don't hesitate to use the contact form below.

By clicking Send, you agree to our Terms and Data Use Policy.

SKU: PD570_PRO_HDMI2.0_HDR Categories: , Tags: , , , ,

Description

Model PD570 PRO HDMI2.0 HDR
Max. Input Resolution 4096×2160p@60/50fps
Recording Mode Software Compression, Real-Time Mode
Interface USB3.0 Type C ( SuperSpeed ) UVC
Video Input 1×HDMI2.0
Video RAW Data Format YUY2, P010 ( Support on outputs below 1080P60 )
NV12, I420 ( Supports on all outputs )
Video Input Resolution USB3.0 Support Resolution
All Resolution Below
4096×2160p@60fps
( 444 10Bit HDR )
Recording Video Format YUY2, P010, NV12, I420 ( USB 3.0 )
UVC Video Output Resolution USB3.0 Support Resolution
4096×2160p@60 / 50fps and 3840×2160p@60 / 50fps inputs will transfer to
3840×2160p@30fps ( NV12, I420 ) or 1920×1080p@60fps ( YUY2, P010 )
For all inputs below 3840×2160p@30fps, PD570C PRO HDMI2.0 HDR outputs will be the same
Audio Input HDMI Embedded Audio
3.5mm Analog Stereo Audio
UAC Audio Output Format Stereo / 16-bit / 48000Hz
System Requirement
OS Support Windows 7 / Windows 8 / Windows 8.1 / Windows 10 ( 32-bit and 64-bit )
Linux / MAC OS / Android

Additional information

Number of Input Channels

1 Channel

Color

Black

Color Precision

NV12, P010, YUY2, I420

Connection Interface

USB3.0

Resolution

4K 30p/25p

Recording Mode

Real Time Mode, Software Compression

Video Input

HDMI
