Description
| Model | SDI to HDMI |
|---|---|
| Description | Converts from SDI to HDMI Provides Two Additional SDI Outputs with Repeater Function |
| Feature | Auto Source Format Detection ( 3G/HD/SD ) Simultaneous 1 × HDMI and 2 × SDI Output Splitter Function Re-Clock Function ( for SDI Output ) Firmware Upgradable Through Mini-USB Port |
| Input Interface | SDI×1 |
| Output Interface | HDMI ( V1.2 )×1 SDI×2 |
| SDI Format | 3G-SDI HD-SDI SD-SDI |
| Supported Video Format | 3G Format 1080p50/60 HD Format SD Format |
| Supported Audio Format | Up to 2 Channels, 24bit, 48KHz |
| Plug & Play | |
| DC In | 7.5V ~ 15V |
