Description
| Model | SDVoE to HDMI2.0-C |
|---|---|
| Description | SDVoE to HDMI 2.0 with Audio and USB HID Converter |
| Feature | 1 USB interface for USB Devices connect 2 RJ45 Connectors for Video and Control Usage Rugged Case Bi-Direction Audio Transfer Supported Bi-Direction IR Transfer Supported RS232 Transfer Supported |
| Input Interface | Video RJ45×1 ( For SDVoE input ) Audio |
| Output Interface | Converted Video HDMI 2.0×1 Audio |
| Supported Video Input Format | RJ45 Network Packet for Video Transfer |
| Supported Video Output Format | HDMI 2.0 ( Converted ) As Input Format |
| Audio Input Format | SDVoE: Up to 8 Channels, 24bit, 48KHz 3.5mm Phone Jack: 2 Channels, 24bit, 48KHz |
| Audio Output Format | HDMI: 8 Channels, 24bit, 48KHz 3.5mm Phone Jack: 2 Channels, 24bit, 48KHz |
| Plug & Play | V |
| DC In | 7.5V ~ 15V |
